Injection Molding Jetting: A Step-by-Step Diagnosis

Jetting is a folded melt stream formed when flow enters an open cavity without establishing stable contact with the mold wall. Confirm the early flow pattern, then test the gate-entry geometry and initial velocity profile. Compare the result against filling, appearance and functional requirements.

What Causes Jetting?

Jetting is a common defect in injection molding. It happens when the molten plastic is pushed through the gate at a very high speed. Instead of flowing smoothly and filling the cavity by hugging the mold walls, it shoots out. It forms a narrow, uncontrolled stream into the open cavity. This stream then folds over itself as more material comes in.

Identifying Jetting

You’ll often see specific signs:

  • Surface marks: Look for a folded, snake-like trail associated with the gate-entry stream. Confirm with controlled short-shot evidence; a photograph alone can be confused with other flow or moisture defects.
  • Weak Parts: The jetting stream cools down too fast. It doesn’t mix well with the plastic that follows it. This poor fusion leads to weaker parts. They might break easily under stress.

Areas Prone to Jetting

Some part designs are more likely to have jetting:

  • Open entry after a restriction: Review whether a narrow gate discharges into an open or suddenly thicker region before the melt contacts a wall.
  • Sudden Wall Thickness Changes: If the plastic flows from a thin section into a much thicker section abruptly, jetting can occur.
    Understanding these basic causes is the first step. Next, we will look at how your mold design plays a big role.

How can you optimize your mold design to stop jetting before it starts?

Optimize your mold by using larger, well-placed gates. Fan or tab gates often help. Check gate impingement and the initial velocity profile first; runner and vent condition are supporting checks. Validate the result on parts.

Gate Design Adjustments

The gate is where the plastic enters the part cavity. It’s a key control point.

  • Gate area and land: At a given volumetric flow rate, a smaller area raises local velocity. Review the entry area and land with filling pressure, gate freeze, vestige, degating and tool strength; simply shortening every gate is not a general solution.
  • Gate location: Evaluate an entry that establishes contact with an appropriate wall or feature. Any added obstruction or part feature must also satisfy stress, appearance, filling and demolding requirements. Confirm the effect in a controlled trial.
  • Gate Type: Different gate types affect flow.
    • Submarine (tunnel) gate: Its suitability depends on exit direction, impingement and material/degating limits; the gate name alone does not establish jetting risk.
    • Fan Gate: Spreads the flow out. This reduces speed and helps prevent jetting.
    • Tab gate. A tab can redirect the incoming melt before it enters an open cavity. Check the flow front with short shots before changing tool steel.
Gate Aspect Problem Leading to Jetting Solution to Reduce Jetting
Size A restrictive gate produces a fast free stream at the required fill rate. Compare entry profiles first. Consider a larger flow area only if trial evidence supports a gate change.
Location Early short shots show melt entering open space before it touches a surface. Assess a gate position that directs the melt toward a cavity wall or obstruction.
Type The current gate does not establish a stable flow front at entry. Compare a fan, tab or revised edge gate against the same short-shot evidence.

Runner System and Venting

  • Runner Design: The channels that carry plastic to the gate (runners) must be smooth. They need to be large enough. Avoid sharp turns between the runner and the gate. These can add pressure loss and disturb the local flow pattern; turbulent polymer flow should not be assumed.
  • Venting: Inspect the actual air-escape path when fill evidence shows trapped gas. Venting supports filling but does not replace correct gate contact or an appropriate entry profile.

Which processing parameters should you adjust first to fight jetting effectively?

Control the velocity as melt first passes through the gate. Check melt and mold temperatures against the actual resin grade, then optimize the remaining fill. Packing cannot undo a folded stream formed during initial filling.

Key Process Parameters to Adjust

  • Injection Speed: This is usually the first thing to check. High injection speed is a direct cause of jetting.
    • Check the entry stage: Test a controlled initial speed through the gate rather than slowing the entire fill without evidence. Preserve the ability to fill thin or distant features within the material window.
    • Profiled Injection: A great technique is to use multi-stage injection. Start with a very slow speed as the plastic goes through the gate. Once the plastic front has established smooth flow and hit an opposite wall, you can increase the speed to fill the rest of the part.
  • Melt Temperature:
    • Increase Melt Temperature: Hotter plastic flows more easily. It has a lower viscosity. This can reduce the chance of jetting. But be careful. Too high a temperature can degrade some plastics. Always check the material supplier’s recommendations.
  • Mold Temperature:
    • Verify mold temperature: Measure the actual thermal condition and compare it with the resin and tool requirements. Trial a justified adjustment within those limits, checking cycle, ejection, dimensions and appearance.

Pressure and Fill Settings

  • Holding pressure: Set pack/hold from gate seal, weight and dimensions after stable filling. It cannot repair a folded stream formed during initial cavity entry.
  • Fill rate. Compare short shots at the same fill fraction. Test the entry velocity separately from the rest of the filling profile.
Parameter Adjustment to Reduce Jetting Why it Helps
Injection Speed Compare a lower gate-entry velocity with the baseline, holding the later fill profile constant. Check whether early short shots contact the cavity wall or form a free strand.
Melt Temperature Check the measured melt temperature against the supplier’s window for the actual grade. Compare flow and surface condition only after confirming the melt is in range.
Mold Temperature Verify the cavity-surface temperature against the qualified range for the material and tool. Compare the surface and fill pattern under the same entry conditions.
Holding Pressure Optimize after fill adjustments Establish weight and dimensions after stable filling; packing does not reverse initial jetting.

Experiment with these settings one at a time. This helps you see what works best for your specific part and material.

How Should a Difficult Jetting Case Be Investigated?

A difficult jetting investigation should combine the observed flow front, gate-entry geometry and a controlled velocity trial. The scenario below illustrates this method. It is not a documented CKMOLD customer case or a guaranteed corrective action.Illustrative workshop tooling review; not an automotive component or evidence of a CKMOLD customer project.

Illustrative Review: An ABS/PC Automotive Component

Consider a hypothetical interior component with thin sections leading to thicker bosses and a gate discharging into an open region. The following steps are a proposed investigation, not observations or outcomes from a CKMOLD project.

  • Initial analysis: Record the actual gate geometry, fill profile and short-shot sequence. Test whether the initial stream enters freely before contacting the cavity wall.
  • Design comparison: Compare a revised impingement direction or a tab/fan entry against the original design. Check the vestige, flow balance, weld locations and demolding before authorizing a steel change.
  • Process trial: Test an initial velocity stage that establishes dispersed flow, then complete the fill within the material window. Verify repeated full parts for appearance, dimensions and required mechanical function.

Checks Beyond the Gate

This illustrative sequence shows how to organize the investigation:

  1. Thorough Part Review: Understand the part geometry. Identify high-risk areas for jetting like those sudden thickness changes or isolated features.
  2. System review: Check runner restrictions, vent condition and local thermal behavior where the observed fill pattern makes them relevant.
  3. Material-specific review: Use the actual grade’s rheology and processing guidance when defining the trial.
  4. Design review before tooling: Review entry contact, flow length, wall transitions and vent paths early. Separate a mold-design change from routine preventive maintenance and validate any proposed flow leader against the complete part requirements.

A Repeatable Short-Shot Check Before Changing Steel

Confirm that the mark follows a folded stream from the gate; distinguish it from a weld line, hesitation mark or moisture-related splay. Under an approved trial procedure, label short-shot samples by cavity, screw position and velocity stage. Keep the resin lot, drying condition and other settings fixed while comparing how the first stream contacts the steel. Do not disable machine guards to observe flow.

Change the gate-entry stage first, then verify full filling, appearance and the part’s functional requirements. Autodesk’s jetting troubleshooting guidance supports evaluating gate contact and the initial velocity profile. Use the material-specific jetting review for resin questions and the gate/process correction guide when choosing a trial action.

For a jetting investigation enquiry, provide the marked defect photographs, CAD revision, gate drawing, resin grade, cavity identification and current process record. Email design files to jerry@ckmold.com after submitting the form.

Conclusion

Confirm the initial flow pattern before changing the gate or velocity profile. Evaluate any adjustment against filling, appearance and functional requirements under the agreed trial conditions.
